Chapter 12 Description of Parameter SettingsMH300
12.1-13-3
Pr. Parameter Name Settings
03-01 ACI analog input selection 1 (Frequency command)
03-28 AVI terminal input selection 0 (0–10 V)
03-29 ACI terminal input selection 1 (0–10 V)
03-31 AFM output selection 0 (0–10 V)
03-50 Analog input curve selection 1 (three-point curve of AVI)
07-06 Restart after momentary power loss
2 (Speed tracking by minimum output
frequency)
07-11 Number of times of auto-restart after fault 5 (times)
07-33 Auto-restart interval of fault 60 (s)
Group setting 04: Pump
The following table lists the pump setting application related parameters.
Pr. Parameter Name Settings
00-11 Speed control mode 0 (IMV/F control mode)
00-16 Duty selection 0 (Normal duty)
00-20
Master frequency command source
(AUTO, REMOTE)
2 (Inputs from external analog)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
00-23 Control of motor direction 1 (Disable reverse)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Motor 1 output frequency Default setting
01-02 Motor 1 output voltage Default setting
01-03 Motor 1 mid-point frequency 1 Default setting
01-04 Motor 1 mid-point voltage 1 Default setting
01-05 Motor 1 mid-point frequency 2 Default setting
01-06 Motor 1 mid-point voltage 2 Default setting
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage Default setting
01-10 Upper frequency limit 50 (Hz)
01-11 Lower frequency limit 35 (Hz)
01-12 Acceleration time 1 15 (s)
01-13 Deceleration time 1 15 (s)
01-43 V/F curve selection 2 (Second V/F curve)
07-06 Restart after momentary power loss
2 (Speed tracking by minimum output
frequency)
07-11 Number of times of auto-restart after fault 5 (times)
07-33 Auto-restart interval of fault 60 (s)
