Chapter 12 Description of Parameter SettingsMH300
12.1-13-4
 Group setting 05: Conveyor
The following table lists the conveyor setting application related parameters.
Pr. Parameter Name Settings
00-11 Speed control mode 0 (IMV/F control mode)
00-16 Duty selection 0 (Normal duty)
00-20
Master frequency command source
(AUTO, REMOTE)
2 (Inputs from external analog)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Motor 1 output frequency Default setting
01-02 Motor 1 output voltage Default setting
01-03 Motor 1 mid-point frequency 1 Default setting
01-04 Motor 1 mid-point voltage 1 Default setting
01-05 Motor 1 mid-point frequency 2 Default setting
01-06 Motor 1 mid-point voltage 2 Default setting
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage of motor 1 Default setting
01-12 Acceleration time 1 10 (s)
01-13 Deceleration time 1 10 (s)
 Group setting 06: Machine tool
The following table lists the machine tool setting application related parameters.
Pr. Parameter Name Settings
00-11 Speed control mode 0 (IMV/F control mode)
00-17 Carrier frequency Default setting
00-20
Master frequency command source
(AUTO, REMOTE)
2 (External analog input)
00-21 Operation command source (AUTO, REMOTE) 1 (External terminals)
01-00 Motor 1 maximum operation frequency Default setting
01-01 Motor 1 output frequency Default setting
01-02 Motor 1 output voltage Default setting
01-03 Motor 1 mid-point frequency 1 0
01-04 Motor 1 mid-point voltage 1 0
01-05 Motor 1 mid-point frequency 2 0
01-06 Motor 1 mid-point voltage 2 0
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage Default setting
01-12 Acceleration time 1 5 (s)
01-13 Deceleration time 1 5 (s)
01-24 S-curve acceleration begin time 1 0
01-25 S-curve acceleration arrival time 2 0
