Chapter 12 Description of Parameter SettingsMH300
12.1-13-5
Pr. Parameter Name Settings
01-26 S-curve deceleration begin time 1 0
01-27 S-curve deceleration arrival time 2 0
02-03 Multi-function input command 3 (MI3) 1 (Multi-step speed command 1)
02-04 Multi-function input command 4 (MI4) 2 (Multi-step speed command 2)
02-13 Multi-function output 1 RY1 11 (Malfunction indication)
02-16 Multi-function output 2 (MO1) 1 (Indication during RUN)
02-17 Multi-function output 3 (MO2) 2 (Operation speed reached)
03-00 AVI analog input selection 1 (Frequency command)
06-01 Over-voltage stall prevention 0 (Disabled)
06-03
Over-current stall prevention during
acceleration
0 (Disabled)
06-04 Over-current stall prevention during operation 0 (Disabled)
06-05
Acceleration / deceleration time selection for
stall prevention at constant speed
0 (By current acceleration/deceleration
time)
07-01 DC brake current level 20 (%)
07-03 DC brake time at stop 0.3 (s)
07-04 DC brake frequency at stop 0 (Hz)
07-23 Auto voltage regulation (AVR) function 1 (Disable AVR)
Group setting 07: Packing
The following table lists the packing setting application related parameters.
Pr. Parameter Name Settings
00-11 Speed control mode 0 (IMV/F control mode)
00-20
Master frequency command source
(AUTO, REMOTE)
0 (Digital keypad)
00-21 Operation command source (AUTO, REMOTE) 2 (RS-485 Communication input)
02-00 Two-wire / three-wire operation control
1 (two-wire mode 1, power on for
operation control (M1: FWD / STOP,
M2: REV / STOP))
01-00 Motor 1 maximum operation frequency Default setting
01-01 Motor 1 output frequency Default setting
01-02 Motor 1 output voltage Default setting
01-03 Motor 1 mid-point frequency 1 Default setting
01-04 Motor 1 mid-point voltage 1 Default setting
01-05 Motor 1 mid-point frequency 2 Default setting
01-06 Motor 1 mid-point voltage 2 Default setting
01-07 Motor 1 minimum output frequency Default setting
01-08 Motor 1 minimum output voltage Default setting
01-12 Acceleration time 1 10 (s)
01-13 Deceleration time 1 10 (s)
