7-6 EMC Filter
Use EMC filters to enhance the EMC performance for the environment and machines and to comply
with EMC regulations, further reducing EMC problems. If you purchase a motor drive without a built-in
EMC filter, it is recommended that you select the EMC filters as shown below. For some motor drive models,
you need to work with zero-phase reactors to be compliant with EMC regulations. Refer to the table and
figure below for the recommended model, setting method, and maximum motor cable length of the EMC
filter and zero-phase reactor.
Frame A–F
Frame
Model
- MH300
Input
Current
(A)
Model
-EMC Filter
Model
-Zero-phase reactor
Conducted emission
Radiated
emission
C1-motor cable
length-30m
C2-motor cable
length-100m
C2-
motor cable
length-100m
Position to place zero-phase reactor
DELTA *1 *2 *3 *1 *2 *3 *1 *2 *3
A
VFD1A6MH11ANSAA 6.8 EMF11AM21A RF008X00A or RF008X00N
NA
VFD2A5MH11ANSAA 10.1 EMF11AM21A
RF008X00A or RF008X00N
NA
VFD1A6MH21ANSAA 5.8 EMF11AM21A
RF008X00A or RF008X00N
NA
VFD2A8MH21ANSAA 8.3 EMF10AM23A
RF008X00A or RF008X00N
NA
VFD1A6MH23ANSAA 2.2 EMF10AM23A
RF008X00A or RF008X00N
NA
VFD2A8MH23ANSAA 3.8 EMF10AM23A
RF008X00A or RF008X00N
NA
VFD5A0MH23ANSAA 6.2 EMF10AM23A
RF008X00A or RF008X00N
NA
VFD1A5MH43ANSAA 2.5 EMF6A0M43A
RF008X00A or RF008X00N
NA
VFD3A0MH43ANSAA 4.6 EMF6A0M43A
RF008X00A or RF008X00N
NA
B
VFD5A0MH21ANSAA 11.7 EMF11AM21A
RF008X00A or RF008X00N
NA
VFD7A5MH23ANSAA 9.6 EMF10AM23A
RF008X00A or RF008X00N
NA
VFD4A2MH43ANSAA 6.4 EMF6A0M43A
RF008X00A or RF008X00N
NA
C
VFD5A0MH11ANSAA 20.6 EMF27AM21B
RF008X00A or RF008X00N
NA
VFD7A5MH21ANSAA 18.5 EMF27AM21B
RF008X00A or RF008X00N
NA
VFD11AMH21ANSAA 27.5 EMF27AM21B
RF008X00A or RF008X00N
NA
VFD11AMH23ANSAA 15 EMF24AM23B
RF008X00A or RF008X00N
NA
VFD17AMH23ANSAA 23.4 EMF24AM23B
RF008X00A or RF008X00N
NA
VFD5A7MH43ANSAA 7.2 EMF12AM43B
RF008X00A or RF008X00N
NA
VFD9A0MH43ANSAA 11.6 EMF12AM43B
RF008X00A or RF008X00N
NA
D
VFD25AMH23ANSAA 32.4 EMF33AM23B RF004X00A or R
F004X00N
NA
VFD13AMH43ANSAA 16.0 EMF23AM43B
RF004X00A or RF004X00N
NA
VFD17AMH43ANSAA 21.8 EMF23AM43B
RF004X00A or RF004X00N
NA
E
VFD33AMH23ANSAA 43.2 B84143D0050R127
RF004X00A or RF004X00N
NA
VFD49AMH23ANSAA 61.2 B84143D0075R127
RF004X00A or RF004X00N
NA
VFD25AMH43ANSAA 30.8 B84143D0050R127
RF004X00A or RF004X00N
NA
VFD32AMH43ANSAA 39.6 B84143D0050R127
RF004X00A or RF004X00N
NA
F
VFD65AMH23ANSAA 82.8 B84143D0090R127
RF004X00A or RF004X00N
NA
VFD38AMH43ANSAA 45.7 B84143D0050R127
RF004X00A or RF004X00N
NA
VFD45AMH43ANSAA 53.9 B84143D0075R127
RF004X00A or RF004X00N
NA
Table 7-55
