14 Protection Parameters (2)
You can set this parameter during operation.

14-00
Extension Card Input Terminal Selection (AI10)

14-01
Extension Card Input Terminal Selection (AI11)
Default: 0
Settings
0: No function
1: Frequency command
(in MH300 series, this function can be the torque limit in torque control mode)
2: Torque command (torque limit in speed mode)
3: Torque compensation command
4: PID target value
5: PID feedback signal
6: PTC thermistor input value
7: Positive torque limit
8: Negative torque limit
9: Regenerative torque limit
10: Positive / negative torque limit
11: PT100 thermistor input value
13: PID compensation value
 1: This function can be the torque limit in torque control mode.
 When you use analog input as PID reference target input, you must set Pr.00-20 to 2 (external
analog input).
Setting method 1: Pr.14-00–14-01 set 1 as frequency command.
Setting method 2: Pr.14-00–14-01 set 4 as PID reference target input.
If the setting value 1 and setting value 4 exist at the same time, AI10 input has highest priority to
become the PID reference target input value.
 When you use analog input as the PID compensation value, you must set Pr.08-16 to 1 (Source
of PID compensation value is analog input). You can see the compensation value with Pr.08-17.
 When you use the frequency command, the corresponding value for 0– ± 10 V / 4–20 mA is
0–maximum operation frequency (Pr.01-00).
 When you use the torque command, the corresponding value for 0– ± 10 V / 4–20 mA is
0–maximum output torque (Pr.11-27).
 When you use torque compensation, the corresponding value for 0– ± 10 V / 4–20 mA is 0–rated
torque.
 When the settings for Pr.14-00 and Pr.14-01 are the same, the AI10 is selected first.
