Chapter 7 Optional AccessoriesMH300
7-59
7-8 Capacitive Filter
Capac
itor Filter is a simple filter accessory, installed to provide simple filtering and eliminating
interference.
Installation diagram
VFD
R
S
T
U
V
W
PE
Motor
PE
G rid
Capacitor
F ilte r
Fig. 7-60
Capacitive filter and drive wiring figure
Fig. 7-61
T/L3
S/L2
R/L1
