Chapter 11 Summary of Parameter Settings
MH300
11-26
05 Motor Parameters
Pr. Parameter Name Setting Range
Default
05-00
Motor parameter auto-tuning
0: No function
1: Dynamic test for induction motor (IM)
2: Static test for induction motor (IM)
4: Dynamic test for PM synchronous motor magnetic pole
5: Rolling auto-tuning for PM (IPM / SPM) motor
12: FOC sensorless inertia estimation
13: High frequency stall test for PM synchronous motor
0
05-01
Full-load current for
induction motor 1 (A)
10120% of the drives rated current
Depending
on the
model
power
05-02
Rated power for induction
motor 1 (kW)
0.00655.35 kW
Depending
on the
model
power
05-03
Rated speed for induction
motor 1 (rpm)
0–xxxxx rpm
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
Depending
on the
motor’s
number of
poles
05-04
Number of poles for
induction motor 1
2–20 4
05-05
No-load current for
induction motor 1 (A)
0.00Pr.05-01 default
Depending
on the
model
power
05-06
Stator resistance (Rs) for
induction motor 1
0.00065.535
Depending
on the
model
power
05-07
Rotor resistance (Rr) for
induction motor 1
0.00065.535
0.000
05-08
Magnetizing inductance
(Lm) for induction motor 1
0.06553.5 mH 0.0
05-09
Stator inductance (Lx) for
induction motor 1
0.06553.5 mH 0.0
05-13
Full-load current for
induction motor 2 (A)
10120% of the drives rated current
Depending
on the
model
power
05-14
Rated power for induction
motor 2 (kW)
0.00655.35 kW
Depending
on the
model
power
05-15
Rated speed for induction
motor 2 (rpm)
0–xxxxx rpm
1710 (60 Hz, 4 poles); 1410 (50 Hz, 4 poles)
Depending
on the
motor’s
number of
poles
