Delta MH300 Series - 9-4 General Specifications

Chapter 9 Specification
MH300
9-8
9-4 General Specifications
Control
Characteristics
Control Method
V/F, SVC, FOC, V/F+PG, FOC+PG, TQC+PG
Applied Motor
IM (Induction Motor), PM motor control (IPM and SPM)
Max. Output
Frequency
0.00–599.00Hz
Starting
Torque*
1
150% / 3 Hz (V/F, SVC, V/F+PG control for IM, Heavy duty)
200% / 0.5 Hz (FOC control for IM, Heavy duty)
200% / 0 Hz (FOC+PG control for IM, Heavy duty)
100% / (1/20 of motor rated frequency) (SVC control for PM, Heavy duty)
150% / 0 Hz (FOC control for PM, Heavy duty)
200% / 0 Hz (Closed loop vector control w/ PG for PM, Heavy duty)
Speed Control
Range*
1
1: 50
1: 100
1: 1000
1: 20
1: 100
1: 1000
(V/F, SVC, V/F+PG control for IM, Heavy duty)
(FOC control for IM, Heavy duty)
(FOC+PG control for IM, Heavy duty)
(SVC control for PM, Heavy duty)
(FOC control for PM, Heavy duty)
(Closed loop vector control w/ PG for PM, Heavy duty)
Overload
Capability
Normal duty:
120% of rated current can endure for 1 minute during every 5 minutes
150% of rated current can endure for 3 seconds during every 30 seconds.
Heavy duty:
150% of rated current can endure for 1 minute during every 5 minutes
200% of rated current can endure for 3 seconds during every 30 seconds
Frequency
Setting Signal
0–10 V / +10– -10 V
4–20 mA / 0–10 V
1 channel pulse input (33 kHz), 2 channel pulse output (33 kHz)
Main Function
Multiple motor switches (maximum eight independent motor parameter settings),
Fast start-
up, Deceleration Energy Back (DEB) function, Wobble frequency function,
Fast deceleration function, Master and Auxiliary frequency source selectable,
Momentary power loss ride thru, Speed search, Over-
torque detection, Torque limit,
16-step speed (max.), Accel./ decel. time switch, S-curve accel. / decel., three-
wire
sequence, JOG frequency, Upper / lower limits for frequency reference, DC injection
braking at start and stop, PID control, Built-
in PLC (5K steps), Positioning function,
Tension control function, Built-in RS-485 (Modbus) and CANopen.
Application
Macro
Built-in application parameter groups (selected by industry) and user-defined
application parameter groups.
Protection
Characteristics
Motor
Protection
Over-current, Over-voltage, Over-temperature, Phase loss, Over-load
Stall Prevention
Stall prevention during acceleration, deceleration and running (independent
settings)
Accessory
Communication
Cards
DeviceNet, EtherNet/IP, Profibus DP, Modbus TCP, EtherCAT
PG Cards
EMM-PG01L (ABZ, Line Driver)
EMM-PG01O (ABZ, Open Collector)
EMM-PG01R (Resolver, applicable to permanent magnet synchronous AC motor )
I/O Extension
Cards
EMM-D33A (Digital Card – 3-in 3-out)
EMM-A22A (Analog Card – 2-in 2-out)
EMM-R2CA (Relay Card, output via 2 C contacts)
EMM-R3AA (Relay Card, output via 3 A contacts)
External DC
Power Supply
EMM-BPS02 (DC 24 V power supply card)
Product Compliance*
2
UL, CE, RCM, RoHS, REACH
Safety Standard*
2
TÜV (SIL 2)
Table 9-7
NOTE:
1. Cont
rol accuracy may vary depending on the environment, application conditions, different motors or encoders.
For details, contact our company or your local distributor.
2. For information on Certifications and Declaration of Conformity (DoC), visit
Delta | Download Center (deltaww.com)
