Chapter 9 Specification
MH300
9-7
460V, three-phase
Frame E F
Model VFD_ _ _ _ _ _ _ _ _SAA
25AMH43_ _ 32AMH43_ _ 38AMH43_ _ 45AMH43_ _
AN EN AF AN EN AF AN EN AF AN EN AF
Applicable Motor Output (kW) 11 15 18.5 22
Applicable Motor Output (HP) 15 20 25 30
Output Rating
*1
Heavy
Duty
Rated Output Capacity (kVA)
19.1 24.4 29 34.3
Rated Output Current (A)
25.0
32.0
38.0
45.0
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA)
21.3 27.4 31.6 37.3
Rated Output Current (A) 28.0 36.0 41.5 49.0
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Input Rating
Rated Input
Current (A)
Heavy Duty 27.5 35.2 41.8 49.5
Normal Duty 30.8 39.6 45.7 53.9
Rated Voltage / Frequency Three-phase, 380–480 V
AC
( -15%– +10 %), 50 / 60 Hz
Operating Voltage Range (V
AC
) 323–528
Frequency Range (Hz) 47–63
Weight (kg) 3.97 5.19 3.97 5.19 6.30 8.56 6.30 8.56
Cooling Method Fan cooling
EMC Filter Optional
Built-
in
Option
al
Built-
in
Option
al
Built-
in
Option
al
Built-
in
Ingress Protection Rating
IP20
IP40
*3
IP20
IP40
*3
IP20
IP40
*3
IP20
IP40
*3
IP20
Frame G H I
Model VFD_ _ _ _ _ _ _ _ _SAA
60AMH43 _ _ 75AMH43 _ _ 91AMH43 _ _ 112MH43 _ _
150MH43 _ _
AN AF AN AF AN AF AN AF AN AF
Applicable Motor Output (kW) 30 37 45 55 75
Applicable Motor Output (HP) 40 50 60 75 100
Output Rating
*1
Heavy
Duty
Rated Output Capacity (kVA) 46.9 57.8 70.3 85.9 117.2
Rated Output Current (A) 60 75 91 112 150
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA) 51.3 63.3 76.9 94 128.2
Rated Output Current (A) 69 85 108 128 180
Carrier Frequency (kHz)
*2
2–15 (Default: 4)
Input Rating
Rated Input
Current (A)
Heavy Duty
63
66
80
110
147
Normal Duty 72.5 77 97 123 173
Rated Voltage / Frequency Three-phase, 380–480 V
AC
( -15 %– +10 %), 50 / 60 Hz
Operating Voltage Range (V
AC
)
323–528
Frequency Range (Hz) 47–63
Weight (kg)
11.7
11.6
25.1
30.6
28.6
32.5
36
42.5
39
48
Cooling Method Fan cooling
EMC Filter
Optional Built-in Optional Built-in Optional Built-in Optional Built-in Optional Built-in
Ingress Protection Rating
IP20
Table 9-6
NOTE:
1. The default is heavy duty mode.
2. The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current.
See the derating curve diagram in Section 9-6.
3. The IP rating of the wiring area (main circuit terminals and control terminals, frame A / B / C / D / E / F) and the
vent near the capacitor (frame C / D / E / F) is IP20.
4. When the load is a shock or impact load, use a higher level model.
