Chapter 7 Optional AccessoriesMH300

7-80

Installation

Model

Screw

Torque

MKM-DRB M4 x P0.7 x 2 pcs

14–16 kg-cm

(12.2–13.8 lb-in.)

(1.38–1.56 Nm)

MKM-DRC M5 x P0.8 x 4 pcs

18–20 kg-cm

(15.7–17.3 lb-in.)

(1.77–1.96 Nm)

Table 7-68

Fig. 7-104
