Electrical Specification
Power supply voltage 15 V
DC
(supplied by AC motor drive)
Insulation voltage 500 V
DC
Communication wire
power consumption
0.85 W
Power consumption 1 W
Weight 23 g
Table 8-17
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 61000-4-2)
EFT (IEC 61800-5-1, IEC 61000-4-4)
Surge Test (IEC 61800-5-1, IEC 61000-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 61000-4-6)
Operation / Storage
Operation: -10–50ºC (temperature), 90% (humidity)
Storage: -25–70ºC (temperature), 95% (humidity)
Shock / Vibration resistance
International standards:
IEC 61800-5-1, IEC 60068-2-6 / IEC 61800-5-1, IEC 60068-2-27
Table 8-18
DeviceNet Connector
PIN Signal Color Definition
5
4
3
2
1
Figure 8-76
1 V+ Red 24 V
DC
2 H White Signal+
3 S - Ground
4 L Blue Signal-
5 V- Black 0 V
Table 8-19
8-10-4 Communication Parameter Settings when Connecting AC Motor Drive to DeviceNet
When you connect the AC motor drive to DeviceNet, set up the communication parameters
based on the table below.
Parameter Function Setting value Description
00-20
Master frequency
command source
8
The frequency command is controlled by the
communication card.
00-21
Operation command
source
5
The operation command is controlled by the
communication card.
09-70
Communication card
address
1 (default) The setting range is 0–63 .
09-71
Communication card
speed
2 (default) 500 Kbps
Table 8-20
