Chapter 8 Option CardsMH300
8-37
Parameter Function Current Set Value Definition of Parameter Values
09-78 IP address 3 1 IP address 192.168.1.5
09-79 IP address 4 5 IP address 192.168.1.5
09-80 Netmask 1 255 Netmask 255.255.255.0
09-81 Netmask 2 255 Netmask 255.255.255.0
09-82 Netmask 3 255 Netmask 255.255.255.0
09-83 Netmask 4 0 Netmask 255.255.255.0
09-84 Default gateway 1 192 Default gateway 192.168.1.1
09-85 Default gateway 2 168 Default gateway 192.168.1.1
09-86 Default gateway 3 1 Default gateway 192.168.1.1
09-87 Default gateway 4 1 Default gateway 192.168.1.1
Table 8-33
8-12-6 LED Indicator Light & Troubleshooting
There are four LED indicator lights on CMM-EIP03: POWER LED displays the status of the working
power, LINK LED displays the connection status of the communication, NET1 displays the network
status, NET2 displays the module status.
LED Indicators
LED Indicators Status Indication Corrective Action
NS
The red and green
lights flash alternately
Self-test of network status No action is required
OFF Network not connected
Check if the network cable is
connected
Red
ON Duplicate IP Check if the IP setting is wrong
Flashes
Communication time out /
disconnected / IP changed
Check if the communication
setting is wrong
Green
ON A CIP connection is established No action is required
Flashes
A CIP connection is not established
after power-on
No action is required
MS
The red and green
lights flash alternately
Self-test of product status No action is required
OFF No power supply Check the power supply
Red
ON An error cannot be restored occurs
Hardware malfunction, contact
with the dealer
Flashes An error can be restored occurs
Check if any parameter setting
is wrong
Green
ON The parameter setting finished No action is required
Flashes No parameter setting
Follow manual instructions to
set parameters
POWER
Orange ON Power supply in normal status No action is required
OFF No power supply Check the power supply
LINK
Orange
On Network connection in normal status No action is required
Flashes Sending / receiving network packet No action is required
OFF Network not connected
Check if the network cable is
connected
Table 8-34
