Chapter 11 Summary of Parameter Settings
MH300
11-31
Pr. Parameter Name Setting Range Default

06-09
Over-torque detection
selection (motor 2)
0: No function
1: Continue operation after over-torque detection during
constant speed operation
2: Stop after over-torque detection during constant speed
operation
3: Continue operation after over-torque detection during
RUN
4: Stop after over-torque detection during RUN
0

06-10
Over-
torque detection level
(motor 2)
10–250%
(100% corresponds to the rated current of the drive)
120

06-11
Over-
torque detection time
(motor 2)
0.1–60.0 sec. 0.1

06-12 Current limit
0–250%
(100% corresponds to the rated current of the drive)
150

06-13
Electronic thermal relay
selection (motor 1)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on shaft)
2: Disable
2

06-14
Electronic thermal relay
action time (motor 1)
30.0–600.0 sec. 60.0

06-15
Temperature level
over-heat (OH) warning
0.0–110.0
ºC
Depending
on the
model
power

06-16 Stall prevention limit level 0–100% (refer to Pr.06-03–06-04) 100
06-17 Fault record 1
0: No fault record
1: Over-current during acceleration (ocA)
2: Over-current during deceleration (ocd)
3: Over-current during steady operation (ocn)
4: Ground fault (GFF)
5: IGBT short circuit between upper bridge and lower
bridge (occ)
6: Over-current at stop (ocS)
7: Over-voltage during acceleration (ovA)
8: Over-voltage during deceleration (ovd)
9: Over-voltage during constant speed (ovn)
10: Over-voltage at stop (ovS)
11: Low-voltage during acceleration (LvA)
12: Low-voltage during deceleration (Lvd)
13: Low-voltage during constant speed (Lvn)
14: Low-voltage at stop (LvS)
15: Phase loss protection (OrP)
0
06-18 Fault record 2 0
06-19 Fault record 3 0
06-20 Fault record 4 0
06-21 Fault record 5 0
06-22 Fault record 6 0
Fault record 7 (Pr.14-70) 0
Fault record 8 (Pr.14-71) 0
Fault record 9 (Pr.14-72) 0
Fault record 10 (Pr.14-73) 0
