Chapter 12 Descriptions of Parameter Settings
MH300
12.1-00-25
 You can switch the HAND, LOCAL mode with the keypad KPC-CC01 (optional) or the multi-
function input terminal (MI) to set the master frequency source.
 It returns to AUTO or REMOTE mode whenever you cycle the power. If you use a multi-function
input terminal to switch between HAND (LOCAL) and AUTO (REMOTE) mode, the highest priority
is the multi-function input terminal.
 The pulse of Pr.00-20 = 4 (Pulse input without direction command) is input by PG or MI7.

00-31
Operation Command Source (HAND, LOCAL)
Default: 0
Settings 0: Digital keypad
1: External terminals
2: RS-485 communication
3: CANopen communication card
5: Communication card (CANopen card not included)
NOTE:
HOA (Hand-Off-
Auto) function is valid only when you use with MO function
setting 41 and 56 or with KPC-CC01 (optional).
 Determines the operation frequency source in the "HAND, LOCAL" mode.
 In the HOA mode, if the multi-function input terminal (MI) function setting 41 and 42 are OFF, the
drive does not receive any operation command and JOG is invalid.

00-32
Digital Keypad STOP Function
Default: 0
Settings 0: Disable STOP key
1: Enable STOP key
 This parameter is valid when the digital keypad is not set as the operation source (Pr.00-21 ≠ 0).
When Pr.00-21 = 0, the STOP key on the digital keypad is not affected by this parameter.
00-33
RPWM Mode Selection
Default: 0
Settings 0: Disabled
1: RPWM mode 1
2: RPWM mode 2
3: RPWM mode 3
 Different control modes for Pr.00-33:
Motor Induction Motor (IM)
Permanent Magnet
Synchronous Motor (PM)
Control Mode VF SVC FOCPG FOC SVC
0: RPWM mode 1
✓
✓
✓
✓
✓
1: RPWM mode 2
✓
✓
✓
✓
✓
2: RPWM mode 3
✓
✓
✓
✓
✓
 When the RPWM function is enabled, the drive randomly distributes the carrier frequency based
on actual Pr.00-17 carrier frequency settings.
 The RPWM function can be applied to all control modes.
