Chapter 12 Description of Parameter Settings
MH300
12.1-05-6
05-33
Induction Motor (IM) or Permanent Magnet Synchronous AC Motor (PM)
Selection
Default: 0
Settings
0: Induction Motor
1: SPM
2: IPM
05-34
Full-load Current for a Permanent Magnet Synchronous AC Motor
Default: Depending on the
model power
Settings 0–120% of the drive’s rated current
05-35
Rated Power for a Permanent Magnet Synchronous AC Motor
Default: Depending on the
motor power
Settings
0.00–655.35 kW
 Sets the rated power for the permanent magnet synchronous motor. The default is the drive’s
power value.
05-36
Rated Speed for a Permanent Magnet Synchronous Motor
Default: 2000
Settings
0–65535 rpm
05-37
Number of Poles for a Permanent Magnet Synchronous Motor
Default: 10
Settings 0–65535
05-39
Stator Resistance for a Permanent Magnet Synchronous Motor
Default: 0.000
Settings
0.000–65.535 Ω
05-40
Permanent Magnet Synchronous AC Motor Ld
Default: 0.00
Settings 0.00–655.35 mH
05-41
Permanent Magnet Synchronous AC Motor Lq
Default: 0.00
Settings 0.00–655.35 mH
05-42
PG Offset Angle for a Permanent Magnet Synchronous Motor
Default: 0
Settings 0.0–360.0°
 When you set Pr.05-00 as 4, the drive detects the offset angle and writes it into Pr.05-42.
05-43
Ke parameter for a Permanent Magnet Synchronous Motor
Default: 0
Settings 0–65535 V/krpm
