Chapter 12 Description of Parameter Settings
MH300
12.1-06-26
The fifth error: ocd occurs after another 1000 minutes.
The sixth error: ocn occurs after another 1000 minutes.
Then Pr.06-17–06-22 and Pr.06-63–06-70 are recorded as follows:
1
st
fault 2
nd
fault 3
rd
fault 4
th
fault 5
th
fault 6
th
fault
Pr.06-17
ocA ocd ocn ocA ocd ocn
Pr.06-18 0 ocA ocd ocn ocA ocd
Pr.06-19
0 0 ocA ocd ocn ocA
Pr.06-20
0 0 0 ocA ocd
ocn
Pr.06-21 0 0 0 0 ocA ocd
Pr.06-22
0 0 0 0 0
ocA
Pr.06-63
1000 560 120 1120 680 240
Pr.06-64 0 1 2 2 3 4
Pr.06-65
0 1000 560 120 1120 680
Pr.06-66
0 0 1 2 2
3
Pr.06-67 0 0 1000 560 120 1120
Pr.06-68
0 0 0 1 2
2
Pr.06-69
0 0 0 1000 560 120
Pr.06-70 0 0 0 0 1 2
※ By examining the time record, you can see that that the last fault (Pr.06-17) happened after the
drive ran for 4 days and 240 minutes.

06-71
Low Current Setting Level
Default: 0.0
Settings 0.0–100.0%

06-72
Low Current Detection Time
Default: 0.00
Settings
0.00–360.00 sec.

06-73
Low Current Action
Default: 0
Settings 0: No function
1: Fault and coast to stop
2: Fault and ramp to stop by the second deceleration time
3: Warn and continue operation
 The drive operates according to the setting for Pr.06-73 when the output current is lower than the
setting for Pr.06-71 and when the time of the low current exceeds the detection time for Pr.06-72.
Use this parameter with the external multi-function output terminal 44 (for low current output).
 The low current detection function does not execute when drive is in sleep or standby status.
