Chapter 5 Main Circuit TerminalsMH300
5-6
Frame AWG
Kit P/N
A
(MAX)
B
(MAX)
C
(MIN)
D
(MAX)
d2
(MIN)
E
(MIN)
F
(MIN)
W
(MAX)
t
(MAX)
H
4
RNB22-8
40.0 11.0 10.0 23.0 8.3 13.0 14.0
*2
24.0 4.5
2
RNBS38-8
1
SQNBS60-8
1/0
SQNBS60-8
2/0
SQNBS80-8
3/0
SQNBS80-8
I
1/0
RNB60-8
50.0 16.0 10.0 27.0 8.3 13.0 14.0 28.0 6.0
2/0
RNB70-8
3/0
RNB80-8
4/0
SQNBS100-8
250
MCM
SQNBS150-8
300
MCM
SQNBS150-8
*1. AWG: Refer to the following tables for the wire size specification for models in each frame.
*2: F(MAX) = 16.5
