Chapter 12 Description of Parameter Settings

MH300

12.1-11-55

Diagram 31

CiA402 object

0x6098H

Z Y X

Function Description

Homing

Method

Home

Limit

Z-phase

Signal

Setting

Homing

Mode

35 - - 8 Use the current position as the origin.

1. The current position is used as the origin (this function is available even when the drive is in stop

status).

A homing failure occurs when the following condition happen:

1. No homing failure condition occurs.
