Chapter 12 Description of Parameter Settings
MH300
12.1-12-16
12-54
Tension Command Source Selection
Default: 0
Settings 0: RS-485 communication input
1: Analog input
 This parameter is valid when Pr.12-00 = 3 or 4.
 When Pr.12-54 = 0, you can use digital keypad, HMI page planning, or text panel (TP series of
PLC products) to change the tension command setting value of Pr.12-56 by using communication.
 When Pr.12-54 = 1, the setting for AVI / ACI analog input selection have to be tension setting value
(Pr.03-00, Pr.03-01 = d18), and Pr.12-56 only can display the value (read only).
12-55
Maximum Tension Value
Default: 0
Settings 0–65535 N
 This parameter is valid when Pr.12-00 = 3 or 4.

12-56
Tension Command Setting Value
Default: 0
Settings 0–65535 N
 This parameter is valid when Pr.12-00 = 3 or 4.
 When Pr.12-54 = 1, Pr.12-56 is read only. Analog input 10V corresponds to Pr.12-55.
12-57
Zero-speed Tension Setting Source
Default: 0
Settings 0: Disabled
1: RS-485 communication input
2: Analog input
 This parameter is valid when Pr.12-00 = 3 or 4.
 When Pr.12-57 = 1, you can use digital keypad, HMI page planning, or text panel (TP series of
PLC products) to change the zero-speed tension setting value (Pr.12-58) by using communication.
 When Pr.12-57 = 2, the setting for AVI / ACI analog input selection have to be zero-speed tension
(Pr.03-00, Pr.03-01 = d19), and Pr.12-58 only can display the value (read only).
 Zero-speed parameters are using for overcoming static friction.

12-58
Zero-speed Tension Setting Value
Default: 0
Settings 0–65535 N
 This parameter is valid when Pr.12-00 = 3 or 4.
 When Pr.12-57 =2, Pr.12-58 is read only. Analog input 10V corresponds to Pr.12-55.
