Chapter 13 Warning Codes|MH300

13-60

ID No.

Display Warning Name Description

Ethernet link fail

(ECEF)

Ethernet cable is not connected

Action and Reset

Action condition Hardware detection

Action time Immediately acts

Warning setting parameter N/A

Reset method Manual reset

Reset condition N/A

Record N/A

Cause Corrective Actions

Ethernet cable is loose Re-connect the cable

Bad quality of Ethernet cable Replace the cable
