Chapter 13 Warning Codes|MH300

13-67

ID No.

Display Warning Name Description

Mail fail (EC3F)

Mail warning: Alarm mail will be sent when the

communication card establishes alarm conditions

Action and Reset

Action condition Communication card establishes alarm conditions

Action time Immediately acts

Warning setting parameter N/A

Reset method Manual reset

Reset condition Immediately resets

Record N/A

Cause Corrective Actions

Communication card

establishes alarm conditions

No actions
