Chapter 14 Fault CodesMH300

14-26

Improper parameter settings for

the speed tracking function

(including restart after

momentary power loss and

restart after fault)

Correct the parameter settings for speed tracking.

1. Start the speed tracking function.

2. Adjust the maximum current for Pr.07-09 speed tracking.
