Chapter 14 Fault CodesMH300

14-28

Torque compensation is too

large.

Adjust the torque compensation (refer to Pr.07-26 torque c

ompensation

gain) until the current reduces and the motor does no stall.

Motor fan error Check the status of the fan, or replace the fan.

Unbalanced three-phase

impedance of the motor

Replace the motor.
