Chapter 14 Fault CodesMH300

14-32

Check if the setting for stall

prevention is correct.

Set the stall prevention to the proper value.

Unbalanced three-phase

impedance of the motor

Replace the motor.

Harmonics are too high. Use remedies to reduce harmonics.
