Chapter 14 Fault CodesMH300

14-90

ID No.

Display Fault Name Description

127

Internal

communication error

(CP33)

Abnormal internal communication

Action and Reset

Action condition Software detection

Action time Immediately act

Fault treatment parameter N/A

Reset method N/A

Record Yes

Cause Corrective Actions

Internal communication error Contact your local distributor or Delta.
