Drive PID control mode
141
P
bit device
Word device
16-bit command (9 STEP)
FPID
Continuous
execution type
FPIDP
Pulse
execution type
32-bit command
－
－
－ －
Flag signal: none
X
Y
M
K
H
KnX
KnY
KnM
T
C
D
S1
＊ ＊ ＊
S2
＊ ＊ ＊
S3
＊ ＊ ＊
S4
＊ ＊ ＊
Notes on operand usage: none
 S
1
: PID reference target value input terminal selection. S
2
: PID function
proportional gain P. S
3
: PID function integral time I. S
4
: PID function differential
time D.
 The FPID command can directly control the drive’s PID feedback control Pr.08-
00 Terminal Selection of PID Feedback, Pr.08-01 Proportional Gain (P), Pr.08-02
Integral Time (I), and Pr.08-03 Differential Time (D).
 When M0=ON, the set PID reference target value input terminal selection is 0 (no
PID function), the PID function proportional gain P is 0, the PID function integral
time I is 1 (units: 0.01 sec.), and the PID function differential time D is 1 (units:
0.01 sec.).
 When M1=ON, the set PID reference target value input terminal selection is 0 (no
PID function), the PID function proportional gain P is 1 (units: 0.01), the PID
function integral time I is 0, and the PID function differential time D is 0.
 When M2=ON, the se
t PID reference target value input terminal selection is 1
(target frequency input is controlled through the digital keypad), the PID function
proportional gain P is 1 (units: 0.01), the PID function integral time I is 0, and the
PID function differential time D is 0.
 D1027: Frequency command after PID operation.
