F
Press [SPINDLE].
The spindle stops.
SPINDLE
ON/OFF
G
Press [ORG.Z].
H
Press [ENTER/PAUSE].
ORIGIN SET Z
Z0
Z -30.00mm
012345678901234567 READY
The machine coordinate is displayed.
The main screen appears again. The coordinate value for Z-axis is set to "0," and the current value is
set to Z0.
X 15.00mm
Y 23.00mm
Z 0.00mm S 5000rpm
012345678901234567 READY
This completes the installation of the end mill.
Using Various Tools
101
Chapter 5 Various Engraving Methods
