2 Fully tighten the solid collet.
Using two wrenches, fully tighten the solid collet.
Wrench
Wrench
3.
Set the lock lever.
Set the lock lever at position.
The spindle head is secured in place.
" P. 62 "Setting the Lock Lever"
Lock lever
Lift up.
4.
Install the cutter and set the Z origin point.
A
Close the front cover.
B
Press [ENTER/PAUSE].
C
Press [ ], [ ], [ ], and [ ] to move the spindle head to the area above the workpiece.
Using Various Tools
108
Chapter 5 Various Engraving Methods
