D
Press [-Z] to lower the spindle head.
Stop at a position where the tip of the solid collet is approximately 10 mm (0.4 in.) away from the
surface of the workpiece.
Workpiece
Solid collet
Approximately 10 mm
(0.4 in.)
E
Press [ORG.Z].
F
Press [ENTER/PAUSE].
Z0
Z -30.00mm
012345678901234567 READY
The machine coordinate is displayed.
The main screen appears again. The coordinate value for Z-axis is set to "0," and the current value is
set to Z0.
X 15.00mm
Y 23.00mm
Z 0.00mm S 5000rpm
012345678901234567 READY
G
Open the front cover.
Using Various Tools
109
Chapter 5 Various Engraving Methods
