Check visually to ensure that no uncut areas remain.
If any parts have not been cut, redo the operation from P. 115 "2. Install the parallel cutter and set the
Z origin.".
MEMO
The initial values for the engraving parameters in the surface leveling data are shown below. Generally,
we recommend that you do not change these settings.
Engraving parameters in the surface leveling data
Depth 0.3 mm (11.8 mil) Spindle 20000 rpm
XY Speed 15.0 mm/sec (0.6 in./sec) Cutting-in Amount 0.15 mm (5.9 mil)
Z Speed 5.0 mm/sec (0.2 in./sec) Tool-up Height 0.5 mm (19.7 mil)
Surface Leveling of the Workpiece Table
117
Chapter 5 Various Engraving Methods
