Getting to know and using tha machine
Integrated devices
C/62
Model E.T. PEGASUS
- CAUTION: - Read the SAFETY REGULATIONS (in this manual) carefully for the safety of all personnel and the machine.
Vkmip/h
RPM
AM
3
(g.105/C)
1
2
Engine errors
(electronic engine only)
Engine errors are signalled by the general alarm pilot light accompanied by an acoustic alarm (buzzer) that lasts for 1.5
seconds and an error code is displayed on the LCD (fig.105/C Pos.“3”). The error is displayed until the operator presses but-
ton “1” (fig.105/C) or “2” (fig.105/C) for 3 seconds. The “general alarm” pilot light will stay on until the error has been removed.
By pressing button “1” (fig.105/C) or “2” (fig.105/C) for 3 seconds, the error is no longer displayed but it is stored in the memory.
One second will lapse before a second error is displayed, the error will be signalled by the buzzer for 1.5 seconds and the new
error will be displayed. The same procedure will apply to every subsequent error.
Error menu
(electronic engine only)
To enter the error menu, press and hold down buttons “1” (fig.105/C) and “2” (fig.105/C) at the same time for 3 seconds.
Press the right button 2 quickly (for less than 3 seconds) to go on to the next error. When you reach the last error “ESC” will be
displayed. To exit, press and hold down the left button “1” for 3 seconds.
Press button “2” (g.105/C) again to start from the rst error again. The panel stores up to ten errors.
If one of the errors is present when the machine is switched on, the panel will switch on the “general alarm pilot light”, sound the
buzzer for 1.5 seconds and the error message will appear on the display. If the error disappears, it is still stored in the memory.
Error messages have priority over service messages.
