E/7
FUSE BOX KEY – DIA. N° E25800-036
POS DESCRIPTION Q.TY
S9 Levellingswitch
S11 Boomheadsolenoidvalveswitch
S12 Manualaxlelockswitch
S13 Leftfrontoutriggerswitch
S14 Rightfrontoutriggerswitch
S15 Revolvinglightswitch
S16 Anti-tippingexclusionswitch
S17 Leftrearoutriggerswitch
S18 Rightrearoutriggerswitch
S20 Airconditionswitch
S21 Parkingbrakeswitch
S22 steeringselectorswitch
S28 Frontwindscreenswitch
S37 START GEAR
S39 STOP LIGHTS MICRO SWITCH
S40 LIGHT SWITCH
S41 Startercontrolboardswitch
S42 BATTERY ISOLATOR SWITCH
S43 AXLE LOCK SENSOR
S44 EXTENSION AND LIFTING DEVICE SENSOR
S45 OPTIONAL PROXIMITY SENSOR
S48 Frontworklightswitch 
S50 Outriggerconsent
S51 footcrossmemberswitch
S52 ALIGNED CAB PROXIMITY SENSOR
S53 BLOCKED CAB PROXIMITY SENSOR
S54 CURRENT SOCKET
S103 Electriccontactswitch
S104 Acceleratorswitch
S105 OUTRIGGER DESCENT SELECTOR
S106 Wheelsalignmentcheckswitch
S106.1 OUTRIGGERS ASCENT SELECTOR
S107 CROSS MEMBER MOVEMENT SELECTOR
S108 FOOT MOVEMENT SELECTOR
S111 Mushroomshapedemergencybuttonswitch
X29 Acceleratorpedal
Y1 FORWARD GEAR SOLENOID VALVE
Y2 REVERSE SOLENOID VALVE
Y4 LEFT LEVELLING SOLENOID VALVE
Y5 RIGHT LEVELLING SOLENOID VALVE
Y6 RIGHT FRONT OUTRIGGER/ RIGHT FRONT OUTRIGGER CROSS MEMBER ASCENT SOLENOID VALVE
Y7 RIGHT FRONT OUTRIGGER/ RIGHT FRONT OUTRIGGER FEET DESCENT SOLENOID VALVE
Y8 LEFT FRONT OUTRIGGER/LEFT FRONT OUTRIGGER CROSS MEMBER ANTERIORE SX
Y9 LEFT FRONT OUTRIGGER/LEFT FRONT OUTRIGGER FEET ANTERIORE SX
Y10 RIGHT REAR OUTRIGGER/ RIGHT REAR OUTRIGGER CROSS MEMBER POSTERIORE DX
Y11 RIGHT REAR OUTRIGGER/ RIGHT REAR OUTRIGGER FEET DESCENT SOLENOID VALVE
Y12 LEFT REAR OUTRIGGER/LEFT REAR OUTRIGGER FEET ASCENT SOLENOID VALVE
Y13 LEFT REAR OUTRIGGER/ LEFT REAR OUTRIGGER FEET DESCENT SOLENOID VALVE
Y14 OUTRIGGERS GENERAL SOLENOID VALVE/OUTRIGGERS DESCENT SELECTION PEGASUS 18/21 mt
