E/8
Mod. E.T. PEGASUS
Electric wiring and system diagrams
FUSE BOX KEY – DIA. N° E25800-036
POS DESCRIPTION Q.TY
Y15 RIGHT REAR AXLE LOCK SOLENOID VALVE.
Y16 LEFT REAR AXLE LOCK SOLENOID VALVE.
Y17 STEERING SOLENOID VALVE
Y18 STEERING SOLENOID VALVE
Y19 STEERING SOLENOID VALVE
Y20 STEERING SOLENOID VALVE
Y21 2ndMECHANICALGEARHURTSOLENOIDVALVE
Y22 1st MECHANICAL GEAR HURT SOLENOID VALVE
Y23 PARKING BRAKE SOLENOID VALVE
Y36 OUTRIGGERS ASCENT SELECTION SOLENOID VALVE PEGASUS 18/21 mt
Y98 AUXILIARY PUMP SOLENOID VALVE
Y99 OUTRIGGERS SOLENOID VALVE
X10.1.p LOWERCABLINEINTERFACECONNECTORWITHBASKETLINE
X10.2.p LOWERCABLINEINTERFACECONNECTORWITHBASKETLINE
X10.3.p LOWERCABLINEINTERFACECONNECTORWITHBASKETLINE
X4 RIGHT DASHBOARD LINE INTERFACE CONNECTOR WITH OPTIONAL LINE
X1 LEFT DASHBOARD LINE INTERFACE CONN. WITH LOW. CAB LINE.
X1 ENGINE LINE INTERFACE CONNECTOR WITH JOINT
X1 ENGINE LINE INTERFACE CONNECTOR WITH DASHBOARD LINE 386
X12 LOW. CAB LINE INTERFACE CON. WITH RIGHT DASHBOARD LINE
X13 LOW. CAB LINE INTERFACE CONN. WITH CONTROL UNIT LINE
X14 LOW. CAB LINE INTERFACE CONN. WITH CONTROL UNIT LINE
X15 UPP. CAB LINE INTERFACE CON. WITH LOW.CAB LINE INTERFACE
X17.1 LOW. CAB LINE INTERFACE CON. WITH SOLENOID VALVES LINE
X17.2 LOW. CAB LINE INTERFACE CON. WITH SOLENOID VALVES LINE
X19 LOW. CAB LINE INTERFACE CON. WITH RIGHT DASHBOARD LINE
X2 LOW. CAB LINE INTERFACE CON. WITH LEFT DASHBOARD LINE
X2.1 LOW. CAB LINE INTERFACE CON. WITH SOLENOID VALVES LINE
X20 LOW. CAB LINE INTERFACE CONN. WITH CONTROL UNIT LINE
X22 LOW. CAB LINE INTERFACE CONN. WITH CONTROL UNIT LINE
X23 LOW. CAB LINE INTERFACE CON. WITH RIGHT DASHBOARD LINE
X25 RIGHT DASHBOARD LINE INTERFACE CONN. WITH LOW. CAB LINE.
X26 LOW. CAB LINE INTERFACE CON. WITH CONTROL UNIT LINE
X3 LEFT DASHBOARD LINE INTERFACE CONN. WITH LOW. CAB LINE.
X32 CURRENT SOCKET
X5 LOW. CAB LINE INTERFACE CONN. WITH PEGASUS TOWER LINE
X6 LOW. CAB LINE INTERFACE CONN. WITH ENGINE LINE
X7 LOW. CAB LINE INTERFACE CONN. WITH CONTROL UNIT LINE
X99 LOW. CAB LINE INTERFACE CONN. WITH CONTROL UNIT LINE
XR OUTRIGGERS MOVEMENT SWITCH DOUBLE RELAY
