BASE SYSTEM KEY - DIA. N° E25800-038F_38.16_400° (mechanical motor)
NAME DESCRIPTION SHEET
A65 PRE-HEATING CONTROL UNIT
A74 ELECTRONIC ACCELERATOR
B23a MOTOR WATER THERMAL CONTACT
B23b IGNITION PLUG THERMISTOR
B24 FUEL LEVEL INDICATOR SENSOR
B23as WATER TEMPERATURE INSTRUMENT THERMOSTAT
B26 MOTOR OIL PRESSRE SWITCH
B27 SEAT MICRO SWITCH
B28 BRAKE PRESSURE SWITCH
B31 ACCUMULATOR PRESSURE SWITCH
B4 REAR OUTRIGGER MICRO SWITCH
B61 FILTER PRE-HEAT THERMISTOR
B63 FRONT OUTRIGGER MICRO SWITCH
B64 SPEED SENSOR
B79 ACCELERATOR LIQUID PRESSURE SWITCH
E1 Right rear work light
E2 Right front work light
E4 Left front work light
E7 CEILING LIGHT
E18 Left rear work light
E22 RIGHT REAR LIGHT
E23 LEFT REAR LIGHT
E24 PLATE LIGHT
E25 RIGHT FRONT LIGHT
E26 LEFT FRONT LIGHT
E27 REVOLVING LIGHT
F1 OUTRIGGERS FUSE 15A
F2 RADIO FUSE 3A
F3 BUZZER AND REVERSE LIGHT FUSE 5A
F4 FAST/SLOW GEAR SELECTOR FUSE 7.5A
F5 OPTIONAL EL CONTROL SWITCH FUSE 5A
F6 ACCELERATOR SWITCH FUSE 7.5A
F7 PNEUMATIC SEAT FUSE 15A
F8 MECHANICAL GEAR FUSE 5A
F9 AXLE LOCK FUSE 10A
F10 SWITCHES LEDS POWER SUPPLY FUSE
F11 LIGHT SWITCH AND STOP LIGHTS POWER SUPPLY FUSE 10A
F12 SENSORS FUSE 3A
F13 OPTIONAL BOOM HEAD SOLENOID VALVE SWITCH FUSE+POWER SUPPLY OPTIONAL LINE 7.5A
F14 POSITION LIGHTS FUSE 5A
F15 POSITION LIGHTS FUSE 5A
F16 FULL BEAM HEADLIGHT FUSE 10 A
F17 HORN FUSE 10A
F18 DIPPED BEAM HEADLIGHT FUSE 10 A
F19 FRONT WINDSCREEN WIPER FUSE 15A
F20 REAR WINDSCREEN WIPER FUSE 15A
F21 OPTIONAL FUSE 15A
F22 FRONT WORK LIGHTS FUSE 20A
F23 REAR WORK LIGHTS FUSE 20A
F24 OPTIONAL FUSE 7.5A
