BASE SYSTEM KEY - DIA. N° E25800-038F_38.16_400° (mechanical motor)
NAME DESCRIPTION SHEET
F25 HEATING FAN FUSE 15A
F26 PARKING BRAKE + START GEAR FUSE 7.5A
F27 ENGINE STOP + SEAT MICRO SWITCH FUSE 7.5A
F28 WARNING FUSE 7.5°
F29 REVOLVING LIGHT FUSE 7.5A
F30 RADIO, CEILING LIGHT AND RADIO CONTROL BATTERY CHARGER FUSE 5A
F31 OPTIONAL FUSE 10A
F32 CURRENT SOCKET FUSE 7.5A
F33 STEERING SELECTOR FUSE 7.5A
F34 AIR CONDITIONER FUSE 15A
F35 OPTIONAL FUSE 15A
F36 INSTRUMENT POWER SUPPLY FUSE 3A
F61 BASKET AND RADIO CONTROL FUSE 15A
F71 ACCELERATOR FUSE SET-UP
F72 POWER SUPP. FUSE SET-UP +30
FG1 ALTERNATOR FUSE 80A
FG2 GENERAL FUSE 80A
FG4 STARTING RELAY FUSE 40A
G1 BATTERY
G2 ALTERNATOR
H2 REVERSE BUZZER
HA1 INSTRUMENT ALARM BUZZER
HA3 HORN
HA4 LEFT SPEAKER
HA5 RIGHT SPEAKER
K1 FULL BEAM HEADLIGHTS RELAY
K1M START RELAY
K2 HORN RELAY
K2M FILTER PRE-HEAT RELAY
K3 DRIVE DISCONNECTION RELAY
K3M HEAT STARTER RELAY
K3PG POWER SUPPLY RELAY +15
K4 BUZZER AND REVERSE LIGHT RELAY
K6 SEAT MICRO SWITCH TIMER
K7 DIPPED BEAM HEADLIGHTS RELAY
K8 DEDALUS ANTI-TIPPING RELAY
K9 HYDRAULIC FAST GEAR RELAY
K10 REVERSE RELAY
K12 OUTRIGGERS PREVENTION RELAY WITH BASKET ENGAGED
K13 OUTRIGGERS INHIBITION RELAY FROM OPTIONAL SENSOR
K14 AUTOMATIC AXLE BLOCK RELAY
K15 FORWARD GEAR RELAY
K17 STEERING SELECTOR RELAY
K18 INHIBITION RELAY FROM LIFTING/EXTEN. SENSOR
K19 LEVELLING LIMITATION RELAY
K20 MECHANICAL GEARS LEDS RELAY
K21 INTERMITTENCE
K5 START SWITCH RELAY WITH GEAR IN NEUTRAL
K60 USERS ABSORPTION EXCLUSIONS RELAY
K73 ACCELERATOR RELAY (OPTIONAL)
K11 START CONSENT FROM CAB RELAY WITH OPERATOR SITTING
