E/37
BASE SYSTEM KEY - DIA. N° E25800-038F_38.16_400° (mechanical motor)
NAME DESCRIPTION SHEET
K16 RUNNING MOTOR FREQUENCY RELAY
KR JOYSTICK SWITCH RELAY
K401 OPTIONAL REVS VARIATION CONTROL UNIT
KS2 Fan 3rd speed relay
M1 STARTER MOTOR
M2 REAR WINDSCREEN WIPER MOTOR
M7 FRONT WINDSCREEN WIPER MOTOR
M8 REAE WINDSCREEN WASHER PUMP
M9 FRONT WINDSCREEN WASHER
M10 FAN MOTOR
M33 Air conditioner motor
P1 INSTRUMENT
R5 FILTER PRE-HEATING
R1 Resistor
R510 Resistor
S0 BATTERY ISOLATOR SWITCH
S1 Emergency switch
S2 Fan switch
S5 Rear windscreen switch
S6 Rear work light switch
S8 Gear change switch
S9 Levelling switch
S11 Boom head solenoid valve switch
S12 Manual axle lock switch
S13 Left front outrigger switch
S14 Right front outrigger switch
S15 Revolving light switch
S16 Anti-tipping exclusion switch
S17 Left rear outrigger switch
S18 Right rear outrigger switch
S20 Air condition switch
S21 Parking brake switch
S22 Steering selector switch
S25 Hydraulicoillterpressureswitch
S28 Front windscreen switch
S34 MECHANICAL GEAR ENGAGED MICRO SWITCH
S35 2nd MECHANICAL GEAR PRESSURE SWITCH ENGAGED
S37 START GEAR
S38 INCHING MICRO SWITCH
S39 STOP LIGHTS MICRO SWITCH
S40 LIGHTS-INDICATORS SWITCH
S43 AXLE LOCK SENSOR
S44 ROTATION SPEED REDUCTION IN END RUN SENSOR
S48 Front work light switch
S50 OUTRIGGERS CONSENT SWITCH
S51 Foot cross member switch
S52 ALIGNED CAB PROXIMITY SENSOR
S53 BLOCKED CAB PROXIMITY SENSOR
S103 Opt. electric control switch
S104 ACCELERATOR SWITCH
