E/38
Mod. E.T. PEGASUS
Electric wiring and system diagrams
BASE SYSTEM KEY - DIA. N° E25800-038F_38.16_400° (mechanical motor)
NAME DESCRIPTION SHEET
S105 OUTRIGGERS DESCENT SELECTOR
S106.1 OUTRIGGERS ASCENT SELECTOR
S107 CROSS MEMBER MOVEMENT SELECTOR
S108 FOOT MOVEMENT SELECTOR
S106 Wheels alignment check switch
S110 RADIO
S111 Emergency
S113 FORKS SWITCH
S114 WINCH SWITCH
S115 BASKET SWITCH
S116 RPM SWITCH
X44 LOW BOOM BY PASS
X54 CURRENT SOCKET
Y0 ENGINE STOP SOLENOID VALVE
Y1 FORWARD GEAR SOLENOID VALVE
Y2 REVERSE SOLENOID VALVE
Y7 RIGHT FRONT OUTRIGGER/RIGHT FRONT OUTRIGGER FEET DESCENT SOLENOID VALVE
Y9 LEFT FRONT OUTRIGGER/LEFT FRONT OUTRIGGER FEET DESCENT SOLENOID VALVE
Y10 RIGHT REAR OUTRIGGER/RIGHT REAR OUTRIGGER FEET ASCENT SOLENOID VALVE
Y12 LEFT FRONT OUTRIGGER/LEFT REAR OUTRIGGER FEET ASCENT SOLENOID VALVE
Y14 OUTRIGGERS GENERAL SOLENOID VALVE/OUTRIGGERS DESCENT SELECTION PEGASUS 18/21mt
Y15 RIGHT REAR AXLE LOCK SOLENOID VALVE
Y16 LEFT REAR AXLE LOCK SOLENOID VALVE.
Y17 STEERING SOLENOID VALVE
Y18 STEERING SOLENOID VALVE
Y19 STEERING SOLENOID VALVE
Y20 STEERING SOLENOID VALVE
Y21 2nd MECHANICAL GEAR HURT SOLENOID VALVE
Y22 1st MECHANICAL GEAR HURT SOLENOID VALVE
Y23 PARKING BRAKE SOLENOID VALVE
Y36 OUTRIGGERS ASCENT SELECTION SOLENOID VALVE PEGASUS 18/21 mt1
Y99 OUTRIGGERS SOLENOID VALVE
X45 basket line CONNECTOR
X46 basket line CONNECTOR
X47 basket line CONNECTOR
X4 opt line CONNECTOR
X1 INTERFACE CONNECTOR L. DRIVER POSITION - L. LEFT DASHBOARD
X1 DASHBOARD CONNECTOR 386
X12 INTERFACE CONNECTOR L. DRIVER POSITION - L. RIGHT DASHBOARD
X13 CONTROL UNIT INTERFACE CONNECTOR RELAY FUSES
X14 CONTROL UNIT INTERFACE CONNECTOR RELAY FUSES
X15 INTERFACE CONNECTOR L. DRIVER POSITION - L. UPPER CAB
X19 INTERFACE CONNECTOR L. DRIVER POSITION - L. RIGHT DASHBOARD
X2 INTERFACE CONNECTOR L. DRIVER POSITION - L. LEFT DASHBOARD
X20 CONTROL UNIT INTERFACE CONNECTOR RELAY FUSES
X21 INTERFACE CONNECTOR L DRIVER POSITION - JOINT
X22 CONTROL UNIT INTERFACE CONNECTOR RELAY FUSES
X23 INTERFACE CONNECTOR L. DRIVER POSITION - L. RIGHT DASHBOARD
X24a POWER SUPPLY CONNECTOR OPTIONAL 9
X25 INTERFACE CONNECTOR L. DRIVER POSITION - L. RIGHT DASHBOARD
X26 CONTROL UNIT INTERFACE CONNECTOR RELAY FUSES
