Troubleshooting
116 Instructions for use Oxylog 3000 plus SW 1.n
Messages in the information field
The numeric values below are examples.
Message Unit
1)
Cause Explanation/Remedy
PEEP >10 mbar has been set
but not confirmed.
The required setting of
PEEP >10 mbar is only pos-
sible when confirmed via the
rotary knob.
Gas consumption = 10 L/min Default display
for current
gas consumption.
(Battery capacity)
Default display for current
battery capacity.
REUS = Adult reusable hose
DISP = Adult disposable hose
PAED = Pediatric disposable
hose
Explanation of abbreviation,
when selecting the hose type
in the Settings window.
Select and confirm hose with
rotary knob.
Breathing hose type has not
been confirmed.
Select and confirm.
REUS = Reusable Cuvette
DISP = Disposable Cuvette
Explanation of abbreviation,
when selecting the CO
2
cuvette type in the Settings
window.
Press Rotary Knob for
Autoset / Exit with Alarm Reset
Activation of Alarms:
Autoset, refer to ”Setting
alarm limits“ on page 87.
After pressing the rotary
knob the new alarm limits
will be set.
Remove sensor from cuvette
then press Rotary Knob
Activation of CO
2 zero
calibration, refer to ”CO
2
measurement (optional)“
on page 91.
After removal of the CO
2
sensor from the cuvette and
pressing the rotary knob, the
zero calibration will proceed.
Cancel by pressing Alarm
Reset.
Place sensor on reference
filter, press rotary knob
Activation of CO
2 filter
check, refer to ”CO
2
measurement (optional)“
on page 91.
After mounting the test filter
and pressing the rotary
knob, the filter check will
start. Cancel by pressing
Alarm Reset.
Pinsp>=PEEP +3 mbar PEEP +3 mbar > Pinsp. Set Pinsp > PEEP +3 mbar.
Confirm PEEP above 10 mbar ?
