DURKOPP ADLER 867 Service Manual

Maintenance
Service Instructions 867 - 04.0 - 10/2019 115
Fig. 97: Cleaning
Areas particularly susceptible to soiling:
• Knife on the winder (4)
• Area under the throat plate (3)
• Hook (2)
• Area around the needle (1)
To clean the machine:
1. Remove any lint and thread remnants using a compressed air gun or
a brush.
(1) - Area around the needle
(2) - Hook
(3) - Area under the throat plate
(4) - Knife on the winder
①
②
④
③

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
