D 13 37
Item Designation Brief description
62
Main function
switch
Detent switch function and LED feedback:
- To lock all functions relevant to paving. Despite
"Auto" settings in the individual functions, these are
not activated when the drive lever is swivelled out.
- Switch OFF by pressing the button again.
A
The preset vehicle can be relocated and released at the
new paving location. The paving process is continued
on swivelling the drive lever out.
A
On restarting, the function is set to "ON".
63
Stop paving +
relief pressure
/
lower screed +
floating position
Button with detent switch function and LED feedback
A
The main function switch must be set to the OFF posi-
tion.
- Button function: Keep the button pressed for longer
than 1.5 seconds (LED ON). The screed is lowered as
long as the button is pressed. When the button is re-
leased, the screed is held in the stop paving + relief
pressure position. (LED ON).
m
Screed may lower slowly!
- Resting function: Press the button briefly (LED ON) -
the screed is lowered. Press the button briefly again -
(LED OFF) the screed is stopped.
- Screed floating position: Pressing the button switches
the LED ON and the screed is in readiness in the
"floating position", which is activated via the swivelled
out drive lever.
- Switch off by pressing the button again or via the lift
screed button.
A
During paving, the screed always remains in its floating
position. During intermediate stops (drive lever in centre
position), the screed is switched to stop paving + relief
pressure.
m
Check whether the screed transport safeguard is insert-
ed!
f
On actuation, note danger zones of moving parts of the
vehicle!
