D 20 6
Main menu
Display and function menu
Displays:
- (1) speed:
- paving operation (m/min)
- driving mode (km/h)
- (2) engine speed (rpm)
- (3) fuel gauge
- (4) engine
coolant temperature (°C)
- (5) engine oil pressure
(bar)
- (6) on-board voltage (V)
- (7) distance travelled counter (m)
- (8) actual temperature of screed heating(°C)
- (9) time of day (hh/mm)
Functions:
A
The functions are activated or deactivated by pressing the adjacent function
button. If the relevant symbol is covered with a red cross, the function is deactivated.
- (C): drive engine "eco mode"
- The engine speed is constantly regulated to 1600 rpm.
- (D): automatic steering unit
- The vehicle is steered automatically via corresponding
sensing along a reference (e.g. cable).
m
When the automatic steering unit is activated, the steering potentiometer is deactivat-
ed.
A
If the driver carries out a steering movement, this overrides the automatic steering
unit due to safety reasons.
- (E): delayed screed start
- On swivelling the drive lever, the screed functions are only activated once the time
set in the relevant menu has elapsed.
