9 Towing
f
Heed all regulations and apply all safety measures applicable for towing heavy con-
struction machines.
m
The towing vehicle must be capable of securing the paver finisher, even on slopes.
Use only approved tow bars!
If necessary, remove any attachments and accessories from the paver finisher and
the screed until the basic width has been attained.
A
Two high-pressure cartridges (6) are
located on both of the travel drive
pumps (5).
The following activities must be carried
out to activate the towing function:
- Loosen lock nut (7) half a turn.
- Screw in the bolt (8) until increased re-
sistance occurs. Then screw the bolt a
further half turn into the high-pressure
cartridge.
- Tighten the lock nut (7) to a torque
of 22 Nm.
m
On completion of the towing process, re-
store the initial status.
7
8
6
5
