D 43 21
Loading/conveying material
- Button (62) has to be switched off.
- Use switch (36)/(37) to open the hopper.
Instruct the truck driver to dump the material.
- Set the switches for the auger (54)/(55) and the conveyor (50)/(51) to "Auto".
- Activate function (64) to fill the vehicle for the paving process.
- Switch the conveyors on.
The conveyor limit switches (A) / (B) must switch off when the material has approx-
imately reached the area beneath the auger crossbeam.
- Check that the material is transferred properly.
Manually switch on or off the conveyor if the material is not conveyed properly until
a sufficient amount of material lies in front of the screed.
