C 13 7
3.4 Loading
m
Pay attention to load distribution during loading!
In some vehicles, the kingpin load is too low so that the load has to be positioned fur-
ther to the back of the vehicle (A).
Always heed the details regarding load distribution stipulated for the vehicle together
with the centre of gravity of the paver finisher.
Comply with the following if the paver finisher has to be placed in the front section of
the low-bed trailer (B) for load distribution reasons or on account of the length of the
paver finisher:
- The paver finisher must stand freely if the push rollers would only touch the goose-
neck half way up (C).
- There must be a positive fit between the paver finisher push rollers and the low-bed
trailer if the push rollers are in full contact with the low-bed trailer (D).
A
B
C
D
