B 16
5.12 Hydraulic system
5.13 Material compartment (hopper)
5.14 Material transfer
5.15 Material distribution
Pressure generation
Hydraulic pumps via distribution gear
(directly flanged to the engine)
Pressure distribution
Hydraulic circuits for:
- Travel drive
- Auger
- Conveyor
- Tamper / vibration
- Operating functions
-Fan
-Clutch
- Separate hydraulic circuits for options
Hydraulic oil reservoir - volume (See chapter F)
Volume
Approx. 6.0 m
3
= approx. 13.0 t
Minimum inlet height, centre 575 mm
Minimum inlet height, outside 585 mm
Hopper width, outside, open 3,460 mm
Type Dual conveyor belt
Width 2 x 580 mm
Conveyors Left and right auger separately controllable
Drive Hydrostatic, continuously controllable
Conveying volume controller Fully automatic via configurable switching points
Auger diameter 380 mm
Drive
- Hydrostatic central drive (o) / hydrostatic
external drive (o)
- Continuously variable, regardless of conveyor
Auger halves can be switched to opposite
direction, reversible direction of rotation
Conveying volume controller Fully automatic via configurable switching points
Auger height adjustment
- Mechanically
- hydraulic (o)
Auger extension With extension parts (see auger extension chart)
