B 2
2 Description of assemblies and functions
Item Designation
1
t
Material compartment (hopper)
2
t
Truck push rollers
3
t
Tube for sensor rod (direction indicator) and holder for levelling shoe
4
t
Rear wheels
5
t
Levelling cylinder for paving thickness
6
t
Traction roller
7
t
Crossbeam pull bar
8
t
Paving thickness indicator
9
t
Crossbeam
10
t
Travel drive
11
t
Auger
12
t
Screed
13
t
Operator’s platform
14
t
Operating panel (can be moved to either side)
15
t
Tandem front axle
16
o
Protective roof
17
o
Working lights
t
=
Standard equipment
o = Optional equipment
12
1
2
7
6
5
8
4
10
13
14
16
9
11
17
15
3
