D 31 3
Control panel, rigid
Operating panel, moveable
The operating panel can be shifted to several positions on the left- and right-hand
sides of the vehicle.
- Release panel latch (1) and slide panel console to the desired position using the
handle (2).
- Insert panel latch (1) into one of the detent positions (3).
m
Make sure it is latched properly!
f
Only adjust the operating position whilst the vehicle is stationary!
