B 11
5.2 Allowed angle of rise and slope
A
Before operating your vehicle in an inclined position (gradient, slope, lateral inclina-
tion) which is above the specified limit value, please consult the customer service de-
partment for your vehicle!
5.3 Permissible approach angle
5.4 Turning circle
Internal turning cycle 2.47 m
External turning cycle 6.06 m
max. 15°
max. 15°
max. 15°
max. 15°
max. 16°
max. 16°
