5.2 Auger extension chart
Symbol Meaning
- (290L)
- Auger blade 290mm
left
- (290R)
- Auger blade 290mm
right
- (434L)
- Auger extension part 434mm
left
- (434R)
- Auger extension part 434mm
right
- (868L)
- Auger extension part 868mm
right
- (868R)
- Auger extension part 868m
right
- (+345L)
- Guide end piece 345mm +
extension left
- (+345R)
- Guide end piece 345mm +
extension right
- (300L)
- Guide
300mm left
- (300R)
- Guide
300mm left
- (300L)
- Guide
300mm left
- (300R)
- Guide
300mm left
- (700L)
- Guide
700mm left
- (700R)
- Guide
700mm left
-(AL)
- Support
left
-(AR)
- Support
right
-(AL)
- Support with shackles
left
-(AR)
- Support with shackles
right
290L 290R
434L 434R
868L 868R
300R
+345R
300L
+345L
300L
300R
300R
500R
300L
500L
700L
700R
AL
AR
ALL
ALR
