Dynapac SD2500W - Control platform, moveable (o)

D 31 4
Control platform, moveable (o)
The control platform can be hydraulically shifted beyond the left/right outer edge of
the vehicle, providing the driver with a better view of the paving area in this position.
- When the control platform has been moved, the windows (1) additionally offer a
good view of the paving area.
A
Refer to the operating panel for actuation of the platform movement function.
m
Shifting the platform increases the basic width of the paver finisher.
f
If the platform is moved, ensure that there is no one in the vehicle's danger area!
f
Only adjust the operating position whilst the vehicle is stationary!
3
2
7
8
1
4
5
